How to make a VR game like The Walking Dead: Saints & Sinners

Intro — What this tutorial gives you

This tutorial shows How To Make A VR Game Like The Walking Dead (stabbing, grab+tear, ragdoll, VFX, haptics) in Unity using the XR Interaction Toolkit. It contains full C# files, explanations, a visual prefab diagram, and inspector value suggestions so a user can assemble a working prefab and prototype quickly.

Visual Prefab Diagram — Zombie (hierarchy & components)

Notes: make sure each limb’s CharacterJoint connects to the torso Rigidbody; ensure ragdoll bodies are initially isKinematic = true until the zombie dies (so animation controls the pose).

Code — Shared interface & pool (must include first)

IDamageable.cs

Single interface that all damageable things implement. NOTE: signature uses 4 parameters so you can pass hit normal and source (weapon).

using UnityEngine;

public interface IDamageable
{
    // amount, hitPoint, hitNormal, source (e.g. weapon)
    void ApplyDamage(float amount, Vector3 hitPoint, Vector3 hitNormal, GameObject source);
}


SimpleObjectPool.cs

Lightweight pool for particles / gore / optional zombies. Call Init() in Awake if you want immediate prefill.

using UnityEngine;
using System.Collections.Generic;

public class SimpleObjectPool : MonoBehaviour
{
    public GameObject prefab;
    public int initial = 10;
    private Queue<GameObject> pool = new Queue<GameObject>();

    public void Init()
    {
        for (int i = 0; i < initial; i++)
        {
            var go = Instantiate(prefab, transform);
            go.SetActive(false);
            pool.Enqueue(go);
        }
    }

    public GameObject Get(Vector3 pos, Quaternion rot)
    {
        GameObject go = pool.Count > 0 ? pool.Dequeue() : Instantiate(prefab, transform);
        go.transform.position = pos;
        go.transform.rotation = rot;
        go.SetActive(true);
        return go;
    }

    public void Return(GameObject go)
    {
        go.SetActive(false);
        pool.Enqueue(go);
    }
}


Code — MeleeWeapon (velocity sampling, stab detection, haptics)

This is the main weapon script. It samples transform delta velocity (works while weapon is parented to the hand), detects stabs (forward-aligned fast hits), spawns hit particles, and triggers haptics via an optional XR controller reference. Attach to your weapon prefab (with a Rigidbody and Colliders). If you’re using XR Interaction Toolkit, add WeaponGrabBinder below to wire haptics automatically.

using UnityEngine;
using UnityEngine.XR.Interaction.Toolkit;

[RequireComponent(typeof(Rigidbody))]
public class MeleeWeapon : MonoBehaviour
{
    [Header("Damage")]
    public float baseDamage = 12f;
    public float minHitVelocity = 1f;
    public float minStabVelocity = 3f;
    public float stabMultiplier = 2.5f;
    public LayerMask damageLayers;

    [Header("Haptics & FX")]
    public XRBaseController referenceController; // optional: set via WeaponGrabBinder on grab
    public float hapticIntensity = 0.5f;
    public float hapticDuration = 0.06f;
    public GameObject hitParticlePrefab;
    public SimpleObjectPool particlePool; // optional pool for particles

    Rigidbody rb;
    Vector3 lastPosition;
    Vector3 velocity;

    void Awake()
    {
        rb = GetComponent<Rigidbody>();
        lastPosition = transform.position;
    }

    void Update()
    {
        // transform-based velocity (works even when parented/kinematic)
        velocity = (transform.position - lastPosition) / Mathf.Max(Time.deltaTime, 1e-6f);
        lastPosition = transform.position;
    }

    void OnCollisionEnter(Collision collision)
    {
        EvaluateHit(collision.collider, collision.GetContact(0).point, velocity);
    }

    void OnTriggerEnter(Collider other)
    {
        EvaluateHit(other, other.ClosestPoint(transform.position), velocity);
    }

    void EvaluateHit(Collider other, Vector3 hitPoint, Vector3 measuredVelocity)
    {
        if (((1 << other.gameObject.layer) & damageLayers.value) == 0) return;
        float speed = measuredVelocity.magnitude;
        if (speed < minHitVelocity) return;

        float forwardDot = Vector3.Dot(measuredVelocity.normalized, transform.forward);
        bool isStab = speed >= minStabVelocity && forwardDot > 0.7f;

        float damage = baseDamage * (speed / minHitVelocity);
        if (isStab) damage *= stabMultiplier;

        var dmg = other.GetComponentInParent<IDamageable>();
        if (dmg != null)
        {
            Vector3 hitNormal = (hitPoint - transform.position).normalized;
            dmg.ApplyDamage(damage, hitPoint, hitNormal, gameObject);

            // spawn particle
            if (particlePool != null && hitParticlePrefab != null)
                particlePool.Get(hitPoint, Quaternion.LookRotation(hitNormal));
            else if (hitParticlePrefab != null)
                Instantiate(hitParticlePrefab, hitPoint, Quaternion.LookRotation(hitNormal));

            // haptics
            if (referenceController != null)
                referenceController.SendHapticImpulse(hapticIntensity, hapticDuration);
        }
    }
}


Explanation — MeleeWeapon

• Velocity sampling: Instead of relying on Rigidbody.velocity (which can be zero while kinematic/parented), we sample transform.position delta each frame to calculate a reliable velocity vector.
• Damage scaling: Damage scales with speed; higher speed => more damage.
• Stab detection: We check the dot product between normalized velocity and weapon forward to see if the motion is a forward thrust; combine this with a minimum speed to classify as a stab and multiply damage.
• Haptics & FX: Optional XRBaseController reference triggers haptics. Hit particle spawns go through a pool if one is provided (recommended for performance).

Code — WeaponGrabBinder (wire XR haptics automatically)

Attach this to the weapon prefab (alongside MeleeWeapon and XRGrabInteractable). It listens for grab events and sets the referenceController on MeleeWeapon so haptics are automatically routed to the grabbing controller.

using UnityEngine;
using UnityEngine.XR.Interaction.Toolkit;

[RequireComponent(typeof(XRGrabInteractable))]
public class WeaponGrabBinder : MonoBehaviour
{
    XRGrabInteractable grab;
    MeleeWeapon melee;

    void Awake()
    {
        grab = GetComponent<XRGrabInteractable>();
        melee = GetComponent<MeleeWeapon>();
        grab.selectEntered.AddListener(OnSelectEntered);
        grab.selectExited.AddListener(OnSelectExited);
    }

    void OnDestroy()
    {
        grab.selectEntered.RemoveListener(OnSelectEntered);
        grab.selectExited.RemoveListener(OnSelectExited);
    }

    void OnSelectEntered(SelectEnterEventArgs args)
    {
        // Try to find XRBaseController on the interactor (the controller object)
        var controller = args.interactorObject.transform.GetComponentInParent<XRBaseController>();
        if (controller != null) melee.referenceController = controller;
    }

    void OnSelectExited(SelectExitEventArgs args)
    {
        melee.referenceController = null;
    }
}


Code — DamageableBase & Ragdoll toggle

Put this on the Zombie root (or torso). Assign all limb Rigidbodies to ragdollBodies in the inspector. We keep limbs kinematic while animated; on death we switch them to dynamic.

using UnityEngine;

[RequireComponent(typeof(Animator))]
public class DamageableBase : MonoBehaviour, IDamageable
{
    public float maxHealth = 120f;
    [HideInInspector] public float currentHealth;
    public Rigidbody[] ragdollBodies;
    public Animator animator;
    public bool enableRagdollOnDeath = true;
    public GameObject deathGorePrefab;
    public SimpleObjectPool gorePool;

    void Awake()
    {
        currentHealth = maxHealth;
        if (animator == null) animator = GetComponent<Animator>();
        if (ragdollBodies != null)
            foreach (var rb in ragdollBodies) rb.isKinematic = true; // animation controls bones while alive
    }

    public virtual void ApplyDamage(float amount, Vector3 hitPoint, Vector3 hitNormal, GameObject source)
    {
        currentHealth -= amount;
        if (currentHealth <= 0f)
            Die(hitPoint, hitNormal, source);
        else
        {
            if (animator) animator.SetTrigger("Hit");
            // Optional: spawn small blood VFX using gorePool
        }
    }

    protected virtual void Die(Vector3 hitPoint, Vector3 hitNormal, GameObject source)
    {
        if (enableRagdollOnDeath) EnableRagdoll(hitPoint, hitNormal);

        if (deathGorePrefab != null)
        {
            if (gorePool != null) gorePool.Get(hitPoint, Quaternion.LookRotation(hitNormal));
            else Instantiate(deathGorePrefab, hitPoint, Quaternion.LookRotation(hitNormal));
        }

        // Default cleanup: disable AI or other scripts (your AI should check for isDead)
        // Example: Destroy after a while
        Destroy(gameObject, 12f);
    }

    public void EnableRagdoll(Vector3 hitPoint, Vector3 hitNormal)
    {
        if (animator) animator.enabled = false;

        if (ragdollBodies != null)
        {
            foreach (var rb in ragdollBodies)
            {
                rb.isKinematic = false;
                rb.AddExplosionForce(220f, hitPoint, 1.2f);
            }
        }
    }
}


Explanation — DamageableBase

• currentHealth: starts at maxHealth. When ≤ 0 we call Die.
• EnableRagdoll: disables the Animator and sets limb rigidbodies to non-kinematic so physics simulates dead body.
• deathGorePrefab: optional big gore spawn at death (pooled if you supplied gorePool).

Code — BreakableLimb (dismemberment on damage)

Place this on each limb GameObject. It tracks accumulated damage and removes the joint once damage passes breakThreshold. It also exposes Detach() which can be triggered by grab logic.

using UnityEngine;

[RequireComponent(typeof(Rigidbody))]
public class BreakableLimb : MonoBehaviour, IDamageable
{
    public float breakThreshold = 40f;
    public GameObject bloodBurstPrefab;
    public SimpleObjectPool bloodPool;

    private float accumulated = 0f;
    private Joint joint;
    private bool detached = false;

    void Start()
    {
        joint = GetComponent<Joint>(); // CharacterJoint or ConfigurableJoint
    }

    // IDamageable implementation
    public void ApplyDamage(float amount, Vector3 hitPoint, Vector3 hitNormal, GameObject source)
    {
        if (detached) return;
        accumulated += amount;
        if (accumulated >= breakThreshold) Detach(hitPoint, hitNormal, source);
    }

    // Manual detach (can be called from LimbGrabTear)
    public void Detach(Vector3 hitPoint, Vector3 hitNormal, GameObject source)
    {
        if (detached) return;
        detached = true;

        // spawn blood
        if (bloodPool != null && bloodBurstPrefab != null)
            bloodPool.Get(hitPoint, Quaternion.LookRotation(hitNormal));
        else if (bloodBurstPrefab != null)
            Instantiate(bloodBurstPrefab, hitPoint, Quaternion.LookRotation(hitNormal));

        if (joint != null) Destroy(joint);
        transform.parent = null;

        var rb = GetComponent<Rigidbody>();
        if (rb != null)
        {
            rb.isKinematic = false;
            rb.AddExplosionForce(300f, hitPoint, 1f);
        }

        // Optionally disable this component so it no longer receives damage
        Destroy(this);
    }
}


Explanation — BreakableLimb

• accumulated: sums incoming damage; on surpassing threshold the limb detaches.
• Detach: removes the joint, makes the limb a free Rigidbody, spawns blood VFX, and optionally destroys this script component to stop further damage processing on that limb.

Code — LimbGrabTear (grab & yank to rip)

Attach to limbs alongside BreakableLimb & XRGrabInteractable. This component measures how hard the player pulls (positional delta), and if it exceeds a threshold it triggers a detach.

using UnityEngine;
using UnityEngine.XR.Interaction.Toolkit;

[RequireComponent(typeof(XRGrabInteractable))]
[RequireComponent(typeof(Rigidbody))]
public class LimbGrabTear : MonoBehaviour
{
    public float tearForceThreshold = 25f;
    XRGrabInteractable grab;
    Rigidbody rb;
    Joint joint;
    Vector3 lastWorldPos;

    void Awake()
    {
        grab = GetComponent<XRGrabInteractable>();
        rb = GetComponent<Rigidbody>();
        joint = GetComponent<Joint>();
        lastWorldPos = transform.position;
    }

    void FixedUpdate()
    {
        if (grab.isSelected)
        {
            Vector3 worldVel = (transform.position - lastWorldPos) / Time.fixedDeltaTime;
            float pulledForce = worldVel.magnitude * rb.mass;

            if (pulledForce >= tearForceThreshold)
            {
                // call BreakableLimb.Detach for safe cleanup
                var br = GetComponent<BreakableLimb>();
                if (br != null) br.Detach(transform.position, -transform.forward, gameObject);
                else
                {
                    if (joint != null) Destroy(joint);
                    transform.parent = null;
                    rb.isKinematic = false;
                    rb.AddForce(worldVel * 2f, ForceMode.Impulse);
                }
            }

            lastWorldPos = transform.position;
        }
        else lastWorldPos = transform.position;
    }
}


Explanation — LimbGrabTear

• worldVel: uses positional delta in FixedUpdate for stable physics sampling.
• pulledForce: approximates the instantaneous yank impulse using mass & velocity magnitude.
• Detach logic: tries to call BreakableLimb.Detach first so pooled blood and cleanup run uniformly.

Code — ZombieAI (NavMeshAgent + Attack)

Simple follower + melee attack. Attach to ZombieRoot. Ensure the scene has a baked NavMesh and assign the player's transform as target.

using UnityEngine;
using UnityEngine.AI;

[RequireComponent(typeof(NavMeshAgent))]
public class ZombieAI : MonoBehaviour
{
    public Transform target;
    public float attackRange = 1.6f;
    public float attackDamage = 10f;
    public float attackCooldown = 2f;
    public Animator animator;
    NavMeshAgent agent;
    float lastAttack = -999f;
    DamageableBase damageableBase;
    bool isDead = false;

    void Awake()
    {
        agent = GetComponent<NavMeshAgent>();
        damageableBase = GetComponent<DamageableBase>();
        if (animator == null) animator = GetComponentInChildren<Animator>();
    }

    void Update()
    {
        if (isDead || target == null) return;

        float dist = Vector3.Distance(transform.position, target.position);
        if (dist > attackRange)
        {
            agent.isStopped = false;
            agent.SetDestination(target.position);
            if (animator) animator.SetFloat("speed", agent.velocity.magnitude);
        }
        else
        {
            agent.isStopped = true;
            if (Time.time - lastAttack >= attackCooldown)
            {
                lastAttack = Time.time;
                if (animator) animator.SetTrigger("Attack");

                // Apply damage to player if present
                var player = target.GetComponent<PlayerHealth>();
                if (player != null) player.ApplyDamage(attackDamage);
            }
        }
    }

    public void DisableAI()
    {
        isDead = true;
        agent.isStopped = true;
    }
}


Code — ZombieSpawner (optional pooling)

Spawner that uses SimpleObjectPool if provided, or falls back to Instantiate. Assign spawn points in inspector.

using UnityEngine;
using System.Collections;

public class ZombieSpawner : MonoBehaviour
{
    public GameObject zombiePrefab;
    public Transform[] spawnPoints;
    public float spawnInterval = 6f;
    public int initialPool = 6;

    SimpleObjectPool pool;

    void Start()
    {
        if (zombiePrefab == null) return;

        var poolGO = new GameObject("ZombiePool");
        poolGO.transform.SetParent(transform);
        pool = poolGO.AddComponent<SimpleObjectPool>();
        pool.prefab = zombiePrefab;
        pool.initial = initialPool;
        pool.Init();

        StartCoroutine(SpawnLoop());
    }

    IEnumerator SpawnLoop()
    {
        while (true)
        {
            Spawn();
            yield return new WaitForSeconds(spawnInterval);
        }
    }

    void Spawn()
    {
        if (spawnPoints.Length == 0) return;
        var p = spawnPoints[Random.Range(0, spawnPoints.Length)];
        var go = pool.Get(p.position, p.rotation);
        // Reset components if necessary (animator, health, AI target)
        var dmg = go.GetComponentInChildren<DamageableBase>();
        if (dmg != null) dmg.currentHealth = dmg.maxHealth;
        var ai = go.GetComponent<ZombieAI>();
        if (ai != null) ai.target = /*your player transform reference here*/ ai.target;
    }
}


Code — PlayerHealth

Basic player health object. Attach to XR Origin or player root and wire references for UI/haptics as needed.

using UnityEngine;

public class PlayerHealth : MonoBehaviour
{
    public float maxHealth = 100f;
    public float currentHealth;
    public UnityEngine.UI.Slider healthSlider; // optional

    void Start()
    {
        currentHealth = maxHealth;
        if (healthSlider != null) healthSlider.maxValue = maxHealth;
    }

    public void ApplyDamage(float amount)
    {
        currentHealth -= amount;
        if (healthSlider != null) healthSlider.value = currentHealth;
        if (currentHealth <= 0) Die();
    }

    void Die()
    {
        Debug.Log("Player died - implement respawn or game over.");
        // e.g., disable input, fade screen, respawn
    }
}


Assembly checklist — Put it together

1. Create folder structure: /Prefabs, /Scripts, /VFX.
2. Create zombie prefab following the visual diagram. Set CharacterJoint connectedBody to Torso Rigidbody for each limb.
3. Assign all limb Rigidbodies to the Torso's DamageableBase.ragdollBodies array.
4. On each limb: add BreakableLimb, XRGrabInteractable (if grabable), LimbGrabTear.
5. Weapon prefab: add MeleeWeapon, Rigidbody, Collider, and WeaponGrabBinder.
6. Create particle prefabs and set up a SimpleObjectPool for blood; assign to MeleeWeapon.particlePool and BreakableLimb.bloodPool.
7. Set MeleeWeapon.damageLayers to include "Enemy".
8. Bake NavMesh; place spawn points and attach ZombieSpawner.

Conclusion & Next steps

You now have a complete, working foundation for a VR zombie melee game with stabbing, ragdoll, and grab+tear dismemberment. Next steps you might want:

• Add audio SFX (impact, scream, detach)
• Create seam-hider gore meshes for detached sockets
• Add pooling for zombies and implement an efficient return-to-pool lifecycle
• Polish hit detection to avoid multi-hit spam (small per-swing cooldown)
